Picasso Lighting · Panel Light
Surface-mounted Nubez stretch-fabric luminous panel for sizes larger than 4x4 ft, specified at 250-625 lm/sq ft (4,000-10,000 lm referenced to a 4x4 panel) in 2700-4000K at 80+ or 90+ CRI.
| Wattage | 44.7–111.8 W |
|---|---|
| Luminous flux | 4000–10000 lm |
| Efficacy | 89 lm/W |
| Color temperature (CCT) | 2700K / 3000K / 3500K / 4000K |
| CRI | ≥80 |
| Mounting | Surface (1/4" threaded rod by others) |
| Dimensions | 5x5 (60" x 60") to 8x8 (96" x 96") squares; 4x5, 5x6, 6x8, 5x10, 8x12 (96" x 144") rectangles; output specified per sq ft |
| Distribution | Direct |
| Finishes | Standard White, Standard Black, Standard Silver, Custom (RAL / Pantone powder coat), Wood finish, Special designer pattern |
| Dimming | 0-10V 1% dimming standard; non-dim and Lutron EcoSystem 1% selectable; PoE, DALI, DMX on request; universal 110-277 VAC |
| Rated environments | Dry, Damp location |
| Rated lifetime | 50,000 h |
| Warranty | 5 years |
Specifications sourced from the manufacturer's datasheet . Verify against the current revision before specifying.
Nubez 4x4 Surface is the surface-mounted member of Picasso Lighting's Nubez stretch-fabric series, which creates a skylight-like luminous ceiling by stretching dual layers of clear and opal-white flexible membrane over a die-formed 20-gauge steel troffer housing with welded, ground corners and no light leaks; the opal-white layer faces the room. Orderable sizes run from 5x5 (60 by 60 in) through 8x8 squares plus 4x5, 5x6, 6x8, 5x10, and 8x12 (96 by 144 in) rectangles, and the series overview cites profiles from squares and rectangles to triangles with custom lumens available. Output is specified per square foot: the published quick-reference table, referenced to a 4x4 panel, lists 4,000 to 10,000 total lumens (250 to 625 lm/sq ft) at 44.7 to 111.8 W and 90 lm/W at 3000K, in 2700K, 3000K, 3500K, and 4000K at 80+ or 90+ CRI (3 SDCM), with tunable white 2700-5000K and RGBW color changing selectable. Drivers are UL-recognized, universal 110-277 VAC with 0-10V 1% dimming standard; non-dim, Lutron EcoSystem 1%, and custom controls are selectable, with PoE, DALI, and DMX available on request, plus options for emergency battery backup, Lutron Athena wireless nodes, and an NRC-0.55 acoustical membrane. Surface-mounted fixtures have pre-drilled holes for 1/4 in threaded rod by others and a 1/2 in knockout for the power feed, and the wider Nubez series is also offered pendant-mounted and recessed in grid, metal, drywall, or wood ceilings. Fixtures are IBEW manufactured and assembled in the USA with a BABAA-compliant ordering option, UL listed for dry and damp locations, rated for 50,000-hour LED life, and covered by a limited five-year warranty.
Pick from Nubez 4x4 Surface's published options to compose a copyable, submittal-ready specification. All choices come from the manufacturer datasheet — confirm the final build against the current revision before ordering.
Submittal summary
