Wall-bracket knife-edge cove system (8-1/2" x 2-5/8") with integral driver, creating a sheetrock cove without framing — 350-1000 lm/ft indirect at 2700-4000K in 2-12 ft lengths.
| Wattage | 3–8.8 W/ft |
|---|---|
| Luminous flux | 350–1000 lm/ft |
| Efficacy | 114 lm/W |
| Color temperature (CCT) | 2700K / 3000K / 3500K / 4000K |
| CRI | ≥80 |
| Mounting | Wall (continuous bracket) |
| Dimensions | 8-1/2" W x 2-5/8" H profile; 2/4/6/8/10/12 ft lengths + custom, up to 12 ft in one piece |
| Distribution | Indirect |
| Finishes | White, Custom (consult factory) |
| Dimming | Non-dim or 0-10V 1% dimming (120/277V); Lutron EcoSystem 1%; Lutron Athena wireless node option; custom controls on request; tunable white 2700-5000K option; universal 110-277 VAC |
| Rated environments | Dry, Damp location |
| Rated lifetime | 50,000 h |
| Warranty | 5 years |
Specifications sourced from the manufacturer's datasheet . Verify against the current revision before specifying.
Knife-Edge is Picasso Lighting's integral-driver cove-building fixture: instead of framing a cove out of sheetrock and wood or metal, the knife-edge extruded-aluminum housing hangs on a continuous wall-mounting bracket screwed to the studs, is covered in sheetrock, and becomes an eight-and-one-half-inch cove on a straight wall or square/rectangular room. The profile is 8-1/2" wide by 2-5/8" tall, extruded in whole-foot increments up to 12 ft in one piece with die-formed aluminum internals and mitered corners; units row continuously with quick-connect and splining hardware supplied, LED boards adjust in position angle, and no low-voltage wiring is needed — 120 or 277 V feeds the back of the fixture. The LED performance table publishes 350, 500, 750, and 1000 lm/ft indirect packages at 3.0-8.8 W/ft (115-118 lm/W at 3000K) behind a clear acrylic diffuser, with custom lumen outputs available. Standard CCTs run 2700K to 4000K in 80+ or 90+ CRI (3 SDCM), with tunable white 2700-5000K available. Lengths are 2, 4, 6, 8, 10, and 12 ft plus custom; drivers are non-dim or 0-10V 1% dimming at 120/277 V, with Lutron EcoSystem 1% and custom controls optional and Lutron Athena wireless nodes, emergency battery driver, inverter wiring, and emergency circuit as options. Standard finish is powder-coated white. IBEW manufactured and assembled in Moonachie, NJ (BABAA compliant option), UL listed for dry and damp locations, rated 50,000-hour LED life, and covered by a limited five-year warranty.
Pick from Knife-Edge's published options to compose a copyable, submittal-ready specification. All choices come from the manufacturer datasheet — confirm the final build against the current revision before ordering.
Submittal summary
