Acoustic wall sconce pairing zero-plastic natural felt with CNC-carved hardwood, delivering a soft 536 lm/ft ambient wall wash at 90+ CRI while adding NRC 0.75–1.0 sound absorption.
| Luminous flux | 536 lm/ft |
|---|---|
| Color temperature (CCT) | 2700K / 3000K / 3500K / 4000K |
| CRI | ≥90 |
| Mounting | Wall (surface, 3/4" offset) |
| Dimensions | Capsule form; Medium 12" × 24", Large 24" × 48"; 3/4" wall offset; polycarbonate tube diffuser |
| Distribution | Direct ambient wall wash |
| Finishes | White Ash (FSC), White Oak (FSC), Walnut (FSC), Cherry (FSC), Hard Maple (FSC), Satin / Danish Oil / ECO zero-VOC clear finishes, Satin Black / Satin White / custom paint, Zero-plastic natural designer felt (full colour range) |
| Dimming | 0-10V, TRIAC/ELV, DALI, or Lutron; integrated or remote Class 2 low-voltage driver |
| Rated environments | Dry, Damp location |
Specifications sourced from the manufacturer's datasheet . Verify against the current revision before specifying.
The Echo Sconce is aaline's acoustic wall luminaire from the Echo Collection — an array of all-natural felt strips nested in CNC-carved hardwood channels that softens the light into a smooth ambient wall wash while balancing sound in the room (NRC 0.75–1.0). It ships in three editions that share the same engine and finishes: the rounded Capsule (EC-SC-CAP), the circular Dot, and the sweeping Arc, each offered in Medium (12" × 24") and Large (24" × 48") sizes with a slim 3/4" wall offset. A polycarbonate tube diffuser delivers 536 lm/ft (custom output on request) at 9.6 W/ft on 110–277V AC 50/60 Hz input (max 100 W), in 2700K, 3000K, 3500K, and 4000K — 90+ CRI across the range, with 80 CRI additionally available at 3500K and 4000K. Dimming is offered in 0-10V, TRIAC/ELV, DALI, and Lutron protocols, with a choice of an integrated driver (junction-box cover plate with threaded-nut detail) or a remote Class 2 low-voltage driver for a minimal, concealed installation. Made from 100% natural materials, the hardwood is FSC-certified — White Ash, White Oak, Walnut, Cherry, or Hard Maple — in Satin (standard), Danish Oil, or ECO zero-VOC clear finishes, or Satin Black / Satin White / custom paint, paired with zero-plastic natural designer felt in the full aaline colour range. The Class A (ASTM E84) fire-rated felt and optional Class A wood treatment make the system compatible with Living Building Challenge requirements; it is rated for dry or damp locations.
Pick from Echo Sconce (Capsule)'s published options to compose a copyable, submittal-ready specification. All choices come from the manufacturer datasheet — confirm the final build against the current revision before ordering.
Submittal summary
