One-inch remote-driver linear with low-glare round micro-cavity optics (UGR<16) in 25/35/45-degree beams, 350-1000 lm/ft direct at 3.9-12.8 W/ft, 2700-4000K.
| Wattage | 3.9–12.8 W/ft |
|---|---|
| Luminous flux | 350–1000 lm/ft |
| Efficacy | 78 lm/W |
| Color temperature (CCT) | 2700K / 3000K / 3500K / 4000K |
| CRI | ≥80 |
| Beam angle | 25° / 35° / 45° |
| Mounting | Pendant (cable, remote-driver canopy), Recessed (trim / trimless), Surface, Wall |
| Dimensions | Nominal 1" x 1" profile; 2/4/6/8 ft nominal lengths + custom (4" increments); continuous rows available |
| Distribution | Direct, Direct/Indirect |
| Finishes | White, Black, Silver, Custom (RAL/Pantone, wood, anodized, chrome/gold plated) |
| Dimming | Remote 0-10V dimming 1% standard; non-dim and Lutron EcoSystem 1% options; DALI/DMX/PoE via factory; universal 110-277 VAC |
| Rated environments | Dry, Damp location |
| Rated lifetime | 50,000 h |
| Warranty | 5 years |
Specifications sourced from the manufacturer's datasheet . Verify against the current revision before specifying.
Sienna 1 Micro Cavity Optic fits recessed round micro-cavity downlight cells (black or white) into Picasso's nominal one-inch-square Sienna profile, achieving a published UGR under 16. The profile is too small for an integral driver, so the cable mounting supports and powers the pendant from a remote-driver canopy; recessed housings (trim or trimless) and surface housings handle the other applications, and the Sienna series is also offered in a wall version. Extruded-aluminum housings come in nominal 2, 4, 6, and 8 ft lengths with custom lengths in 4 in increments and continuous rowing available. The performance table publishes direct output from 350 lm/ft at 3.9 W/ft (88 lm/W) to 1000 lm/ft at 12.8 W/ft (78 lm/W) at 3500K, with indirect packages from 350 to 1000 lm/ft drawing 2.1-6.3 W/ft at up to 170 lm/W. Direct beams are 25, 35, or 45 degrees; indirect optics include Lambertian, 120-degree batwing, flat 150-degree, and asymmetric lenses. CCTs are 2700K-4000K (tunable white and warm dim on request) in 80+ or 90+ CRI, with remote 0-10V 1% dimming, non-dim, Lutron EcoSystem 1%, and custom controls at universal 110-277 VAC. BABAA-compliant ordering is offered; fixtures are IBEW-manufactured in the USA, UL listed for dry and damp locations, rated 50,000 hours, with a limited five-year warranty.
Pick from Sienna 1 Micro Cavity Optic's published options to compose a copyable, submittal-ready specification. All choices come from the manufacturer datasheet — confirm the final build against the current revision before ordering.
