Slim 1-3/8" wide by 2" tall remote-driver linear LED pendant with a flush frosted lens, 350 or 500 lm/ft direct plus optional indirect, 2700-4000K, in 2-8 ft lengths.
| Wattage | 5.01–7.03 W/ft |
|---|---|
| Luminous flux | 350–500 lm/ft |
| Efficacy | 71 lm/W |
| Color temperature (CCT) | 2700K / 3000K / 3500K / 4000K |
| CRI | ≥80 |
| Mounting | Pendant (aircraft cable, remote driver), Surface, Recessed, Wall |
| Dimensions | 1-3/8" W x 2" H profile; 2/3/4/6/8 ft nominal lengths + custom (1 in. increments), continuous rows available |
| Distribution | Direct, Direct/Indirect |
| Finishes | White, Black, Silver, Custom (RAL/Pantone powder coat, woodgrain, anodized, chrome/gold plating) |
| Dimming | Remote 0-10V 1% dimming (120V or 277V); remote non-dim, Lutron EcoSystem 1%, Lutron Athena wireless node; DALI/DMX/PoE on request; universal 110-277 VAC |
| Rated environments | Dry, Damp location |
| Rated lifetime | 50,000 h |
| Warranty | 5 years |
Specifications sourced from the manufacturer's datasheet . Verify against the current revision before specifying.
Blade 2 Flush Lens pairs the slimmest 1-3/8" wide by 2" high profile of Picasso Lighting's minimalist Blade series with an extruded snap-in frosted acrylic lens set flush with the extruded-aluminum end caps; the profile is too small to house a driver, so power comes from a remote driver through the low-voltage support cables. Nominal lengths run 2, 3, 4, 6, and 8 ft plus custom sizes in 1-inch increments, and fixtures may be continuously rowed (contact factory). Output is 350 or 500 lm/ft direct (5.01-7.03 W/ft, 66-68 lm/W at 3000K) with optional 350 or 500 lm/ft indirect (2.7-3.9 W/ft) through Lambertian, 120-degree batwing, 150-degree flat, or asymmetric uplight lenses; CCTs are 2700/3000/3500/4000K at 80+ or 90+ CRI, with tunable white (2700-5000K) and custom lumen tuning offered. Remote drivers are universal 110-277 VAC with 0-10V 1% dimming standard; remote non-dim, Lutron EcoSystem 1%, and Lutron Athena wireless-node options are published, with DALI/DMX/PoE and remote emergency battery-backup drivers available. Cable mounting uses gripper-style locking on standard 4 ft cables to round, square, or compact rectangular remote-driver canopies, and surface-mount housings with integral drivers are also published; the Blade series is additionally offered in Recessed, Surface, and Wall versions. Fixtures are IBEW manufactured and assembled in the USA, UL listed for dry and damp locations, with 50,000-hour rated LED life and a five-year limited warranty.
Pick from Blade 2 Flush Lens's published options to compose a copyable, submittal-ready specification. All choices come from the manufacturer datasheet — confirm the final build against the current revision before ordering.
Submittal summary
