OCL Architectural Lighting · Pendant
Minimal LED pendant from OCL on a 1.75 in square profile with silicone diffuser, offered in five diameters (24–72 in) and three distributions (inner, outer, down), delivering 1,551–8,084 delivered lumens at 80+/90+ CRI across 2700–4000K, with an acoustic version available.
| Wattage | 26–134 W |
|---|---|
| Luminous flux | 1551–8084 lm |
| Efficacy | 60 lm/W |
| Color temperature (CCT) | 2700K / 3000K / 3500K / 4000K |
| CRI | ≥80 |
| Mounting | Pendant (suspended) |
| Dimensions | 24 / 36 / 48 / 60 / 72 in diameter; 1.75 × 1.75 in square profile; distributions: Inner (SE1), Outer (SE2), Down (SE3) |
| Distribution | Direct/Indirect (Inner / Outer), Direct (Down) |
| Finishes | Matte White, Sky White, Black, Black Textured, White Textured, Silver Metallic, Brass Metallic, Goldtastic, Steel Gray, Bronze, Graphite, Brushed Aluminum (metal) |
| Dimming | 0-10V (1%) standard; dual 0-10V, DALI, or DMX to 0.1% |
| Rated environments | Dry, Damp location (ULD option) |
| Warranty | 5 years |
Specifications sourced from the manufacturer's datasheet . Verify against the current revision before specifying.
Stealth is OCL's minimal ring pendant, an extruded-aluminum body with a silicone diffuser that eliminates pixelation on an extremely slim 1.75" × 1.75" square profile. It is offered in five diameters — 24", 36", 48", 60", and 72" — and three distribution styles: SE1 Stealth Inner (inward glow), SE2 Stealth Outer (outward glow), and SE3 Stealth Down (downlight). Published delivered lumens (3500K, 80+ CRI) span the three styles closely: LED1 delivers about 1,551–1,566 lm (26–33 W) at 24" rising to 4,794–4,806 lm (80–102 W) at 72"; the higher LED2 output delivers about 2,520–2,585 lm (42–47 W) at 24" rising to 8,040–8,084 lm (134 W) at 72". The light source is available at 2700K, 3000K, 3500K, and 4000K in 80+ CRI (also 90+ CRI, R9 > 50, apply a 0.85 lumen multiplier), plus tunable white, warm-dim, and RGBW options (data pending LM-79). Hanging systems use aircraft cables and a power cord with a field-adjustable overall height; fixtures can be clustered and custom sizes and shapes are available. The welded extruded-aluminum body carries OCL's powder-coat and premium-metal finish palette. Dimming is 0-10V to 1% standard, with dual 0-10V, DALI, and DMX to 0.1% optional. Running on 120–277V, Stealth is ETL listed to UL 1598 for dry locations (damp label optional), BABA compliant, RoHS compliant, and carries a 5-year warranty. A Stealth Acoustic version adds sound-absorbing panels. Designed and fabricated in St. Louis, Missouri.
Pick from Stealth's published options to compose a copyable, submittal-ready specification. All choices come from the manufacturer datasheet — confirm the final build against the current revision before ordering.
Submittal summary
