OCL Architectural Lighting · Pendant
OCL's Schoolhouse decorative pendant pairs a hand-blown opal white glass globe (14, 16 or 18 in diameter) with a solid brass or aluminum fitter, delivering 1,480 lm (LED1, 20 W) or 1,850 lm (LED2, 25 W) at up to 74 lm/W.
| Wattage | 20–25 W |
|---|---|
| Luminous flux | 1480–1850 lm |
| Efficacy | 74 lm/W |
| Color temperature (CCT) | 2700K / 3000K / 3500K / 4000K |
| CRI | ≥80 |
| Mounting | Pendant (single center stem, P1AA), Ceiling, Wall (sconce) |
| Dimensions | Hand-blown opal white glass globe in 14, 16 or 18 in diameter (8, 9.5 or 12 in glass height); pendant OAH 21–161 in |
| Distribution | Direct/Indirect |
| Finishes | Matte White, Black, Brass Metallic, Bronze, Black Textured, White Textured, Graphite, Goldtastic, Steel Gray, Silver Metallic, Sky White, Polished Aluminum, Brushed Aluminum, Pewter, Polished Brass, Brushed Brass, Antique Brass, Statuary Bronze, Satin Nickel, Oil Rubbed Bronze, RAL / Pantone / custom |
| Dimming | 0-10V dimming to 1% standard (DM1); optional BIOS SkyBlue / SkyBlue Dynamic circadian engine; universal 120–277V input; Bridgelux COB; field-replaceable driver |
| Rated environments | Dry, Damp (optional ULD label) |
| Warranty | 5 years |
Specifications sourced from the manufacturer's datasheet . Verify against the current revision before specifying.
Schoolhouse is OCL Architectural Lighting's take on the classic schoolhouse pendant — a hand-blown, opal white glass globe (minimum 0.150 in wall thickness) mounted to a solid non-ferrous brass or aluminum fitter. The fixture body is spun, extruded and machined aluminum or brass and the light source is a Bridgelux COB array. It is offered in three globe diameters: 14 in (8 in glass height, 15 lb), 16 in (9.5 in, 18 lb) and 18 in (12 in, 22 lb). Delivered output (measured at 3500K, 80+ CRI) is 1,480 lm at 20 W for the LED1 tier and 1,850 lm at 25 W for the LED2 tier, at up to 74 lm/W (per the SC1-P1AA-16 LED2 photometric test, report no. 13761); the opal globe distributes light symmetrically, roughly 50% down and 50% up. Values scale by 0.95 for 2700K, 0.97 for 3000K and 1.03 for 4000K, and 90+ CRI output uses a 0.85 multiplier. Color temperatures are 2700K, 3000K, 3500K and 4000K in 80+ CRI (R9 > 0) or 90+ CRI (R9 > 50). The P1AA pendant hangs from a single center stem with a 45-degree sloped-ceiling canopy and mounts to a 4×4 in octagon or 4 in round junction box; the Schoolhouse series is also offered in ceiling and wall (sconce) versions. Fixtures run on universal 120–277V input with 0-10V dimming to 1% standard (DM1) and a field-replaceable driver; an optional BIOS SkyBlue / SkyBlue Dynamic circadian light engine contributes toward WELL Building Standard circadian features. Finishes cover an extensive palette of powder coats (matte white, black, brass metallic, bronze, black and white textured, graphite, goldtastic, steel gray, silver metallic, sky white) and premium metals (polished and brushed aluminum, pewter, polished/brushed/antique brass, statuary bronze, satin nickel, oil rubbed bronze), plus RAL, Pantone and custom. ETL listed to UL 1598 for dry locations (optional damp label) and backed by a five-year limited warranty.
Pick from Schoolhouse's published options to compose a copyable, submittal-ready specification. All choices come from the manufacturer datasheet — confirm the final build against the current revision before ordering.
Submittal summary
