OCL Architectural Lighting · Pendant
OCL's Camelot is a solid non-ferrous brass decorative bowl luminaire with a classic egg-and-dart trim ring, offered in 25 in (shallow, CM1) and 32 in (deep, CM2) diffusers as pendant, ceiling, and sconce mounts, delivering 4,500 lm (LED1) or 9,100 lm (LED2).
| Wattage | 50–105 W |
|---|---|
| Luminous flux | 4500–9100 lm |
| Efficacy | 87 lm/W |
| Color temperature (CCT) | 2700K / 3000K / 3500K / 4000K |
| CRI | ≥80 |
| Mounting | Pendant (suspended), Surface ceiling, Wall sconce |
| Dimensions | 25 in dia (CM1 shallow diffuser) or 32 in dia (CM2 deep diffuser) |
| Finishes | Black, Brass Metallic, Bronze, Black Textured, Graphite, Goldtastic, Matte White, Steel Gray, Silver Metallic, Sky White, White Textured, Pewter, Polished Brass, Brushed Brass, Antique Brass, Statuary Bronze, Satin Nickel, Oil Rubbed Bronze |
| Dimming | 0-10V (1%) |
Specifications sourced from the manufacturer's datasheet . Verify against the current revision before specifying.
The Camelot is OCL Architectural Lighting's recreation of a historical classic: a bowl luminaire whose trim ring is cast from solid, non-ferrous brass and features the classic egg-and-dart architectural detail, with an optional V-style overlay and acorn-style cast-brass bottom finial. Its thermally formed acrylic diffuser ranges from 3/16 to 1/4 in thick depending on size — virgin white acrylic is UV-stable (UL-94 HB flame class) and all faux acrylic colors are mixed completely through to avoid noticeable fading. The family is offered as a Camelot Pendant, Ceiling, Sconce, and Signature Pendant, in a 25 in shallow diffuser (CM1) and a 32 in deep diffuser (CM2). The LED source delivers 4,500 delivered lumens at 50 W (LED1) or 9,100 delivered lumens at 105 W (LED2) at 3500K with standard white acrylic (0.95 multiplier at 2700K, 0.97 at 3000K, 1.03 at 4000K), on universal 120–277 V drivers with 0-10V 1% dimming; a screw-in incandescent option (three E26 A19 sockets, 100–150 W max per lamp) is also available on 120 V. Diffusers come in Gloss White, Matte White, Faux Alabaster, and White Swirl acrylic, and metal is finished in eleven powder-coat colors plus seven premium hand-applied metal finishes.
Pick from Camelot's published options to compose a copyable, submittal-ready specification. All choices come from the manufacturer datasheet — confirm the final build against the current revision before ordering.
Submittal summary
