C3160 flush / semi-flush ceiling luminaire with an Acrylic bowl diffuser and decorative pierced metal ring, offered with an optional integrated LED engine delivering 5,200–11,200 delivered lumens at 3000K, >80 CRI.
| Wattage | 47–92 W |
|---|---|
| Luminous flux | 5200–11200 lm |
| Efficacy | 122 lm/W |
| Color temperature (CCT) | 3000K |
| CRI | ≥80 |
| Mounting | Flush mount, Semi-flush mount |
| Dimensions | Four diameters: 16", 22", 30", 42". Flush height (incl. ring, diffuser, ball finial): 7", 9", 9¾", 13". Semi-flush height: 11", 14", 15¾", 21". |
| Finishes | Brushed Nickel, Polished Brass, Polished Nickel, Satin Brass |
| Dimming | 0–10VDC, 1% (LED option) |
Specifications sourced from the manufacturer's datasheet . Verify against the current revision before specifying.
Corinth (C3160) is a flush and semi-flush ceiling luminaire from ILEX Architectural Lighting: an Acrylic bowl diffuser set into a decorative pierced metal ring with a ball finial. It is offered in four diameters — 16", 22", 30" and 42" — as either a Flush Mount or Semi-Flush Mount. With the optional integrated LED engine it delivers 5,200 lm (18", 47 W), 7,000 lm (24", 62 W), 9,000 lm (30", 70 W) or 11,200 lm (36", 92 W), all at 3000K and >80 CRI, on 120–277V with 0–10VDC dimming to 1%. As a standard incandescent fixture it takes (1) 60W medium-base Edison lamp in the Flush configuration or (3) 60W lamps in the Semi-Flush configuration. Finishes are Brushed Nickel, Polished Brass, Polished Nickel and Satin Brass, with custom finishes available; all finishes are now powder coat. Corinth is UL/ETL listed and made in ILEX's Michigan facility.
Pick from Corinth's published options to compose a copyable, submittal-ready specification. All choices come from the manufacturer datasheet — confirm the final build against the current revision before ordering.
Submittal summary
