Edge-lit circular architectural luminaire in suspended and ceiling versions, delivering 4,725–9,450 lm from Nichia LEDs at CRI > 90.
| Wattage | 108–216 W |
|---|---|
| Luminous flux | 4725–9450 lm |
| Efficacy | 44 lm/W |
| Color temperature (CCT) | 2700K / 3000K / 3500K / 4000K / 5700K |
| CRI | ≥90 |
| IP rating | IP40 |
| Mounting | Suspended, Ceiling |
| Dimensions | Ø1000–Ø2000 mm × 100–200 mm |
| Distribution | Direct |
| Finishes | White, Black, Custom RAL/NCS/Pantone |
| Rated lifetime | 60,000 h |
| Warranty | 2 years |
Specifications sourced from the manufacturer's datasheet . Verify against the current revision before specifying.
Groove is a Folio architectural circular luminaire built from aluminum and methacrylate with a Nichia LED source. It is offered in suspended and ceiling mountings across three diameters (Ø1000, Ø1500, Ø2000 mm; 100–200 mm profile) delivering 4,725 lm to 9,450 lm, with static CCTs of 2700/3000/3500/4000/5700 K and CRI Ra ≥ 90 (R9 ≥ 50). Available with remote or integrated power supply on a 24 V DC input, dimmable, rated IP40 with an L90 > 60,000-hour rated lifespan.
Pick from Groove's published options to compose a copyable, submittal-ready specification. All choices come from the manufacturer datasheet — confirm the final build against the current revision before ordering.
Submittal summary
