Recessed linear from the Vario series with a flush opal snap-in lens, 350-1,000 lm/ft direct output, 2700-4000K or tunable white, in 4/6/8 ft and custom lengths for grid, Tech Zone, and drywall ceilings.
| Wattage | 4.28–12.63 W/ft |
|---|---|
| Luminous flux | 350–1000 lm/ft |
| Efficacy | 79 lm/W |
| Color temperature (CCT) | 2700K / 3000K / 3500K / 4000K |
| CRI | ≥80 |
| Mounting | Recessed (9/16" / 15/16" T-grid), Recessed (S-slot grid / Tech Zone), Recessed (drywall trim / trimless), Pendant, Surface |
| Dimensions | 4/6/8 ft nominal lengths + custom lengths in 1" increments; continuous rows available |
| Distribution | Direct |
| Finishes | White, Black, Silver, Custom (RAL/Pantone powder coat, wood, anodized aluminum, chrome/gold plating) |
| Dimming | 0-10V 1% dimming standard; non-dim, Lutron EcoSystem 1%, Lutron Athena wireless node, custom controls; DALI/DMX/PoE on request; universal 110-277 VAC |
| Rated environments | Dry, Damp location |
| Rated lifetime | 50,000 h |
| Warranty | 5 years |
Specifications sourced from the manufacturer's datasheet . Verify against the current revision before specifying.
Vario Linear Recessed is the linear-only recessed member of Picasso Lighting's Vario series, designed mainly for retail, office, and library settings. The extruded-aluminum housing comes in nominal 4, 6, and 8 ft lengths plus custom lengths in 1-inch increments, may be continuously rowed, and mounts in S-slot grid, T-bar, and Tech Zone ceilings with 9/16" and 15/16" tee options, plus trim and trimless versions for sheetrock. Its opal-white snap-in lens is designed for high LED output while hiding the LED image, with delivered output of 350, 500, 750, or 1,000 lm/ft (4.28-12.63 W/ft at 3000K, 80-81 lm/W). Standard CCTs run 2700K to 4000K with 80+ or 90+ CRI, plus tunable white 2700-5000K on linear sections; drivers are high-power-factor universal 110-277 VAC with 0-10V 1% dimming standard and non-dim, Lutron EcoSystem, Lutron Athena wireless, emergency-battery, and PoE/DALI/DMX options. The Vario series is also available in Pendant and Surface versions and in custom shapes such as triangles, squares, and rectangles. Fixtures are IBEW-manufactured and assembled in the USA, UL listed for dry and damp locations, rated for 50,000-hour LED life, and covered by a limited five-year warranty.
Pick from Vario Linear Recessed's published options to compose a copyable, submittal-ready specification. All choices come from the manufacturer datasheet — confirm the final build against the current revision before ordering.
Submittal summary
