A 6"×22" die-cast LED linear fixture with swiveling arms (-15° to +110°) — delivering 6,500 to 18,000 delivered lumens at up to 190 lm/W, UGR<19 dark-light optics, and track, suspended or recessed mounting.
| Wattage | 30–106 W |
|---|---|
| Luminous flux | 6500–18000 lm |
| Efficacy | 170 lm/W |
| Color temperature (CCT) | 2700K / 3000K / 3500K / 4000K / 5000K |
| CRI | ≥90 |
| Beam angle | 35° / 50° / 80° |
| Mounting | Track (Stucchi 2C/3C), Suspended (5 ft), Pendant (aircraft cable, 10/15 ft), Recessed, Trimless recessed |
| Dimensions | 6" × 22" × 3", 4.8 lb (2.5 kg); swiveling arms -15° to +110°; recessed cut-out ~9" × 25" |
| Distribution | Asymmetric (aisle), Wall wash, Flood 35°, Medium wide 50°, Wide 80° |
| Finishes | RAL 9016 White, RAL 9005 Black, RAL 9006 Silver, Custom color |
| Dimming | 0-10V, DALI, ON/OFF; 120/277/347V input |
| Rated environments | Dry |
| Rated lifetime | 50,000 h |
| Warranty | 5 years |
Specifications sourced from the manufacturer's datasheet . Verify against the current revision before specifying.
Suncatcher is ON LIGHT's 6" × 22" die-cast aluminium LED linear fixture with dual swiveling arms that pivot from -15° to +110° for adjustable accent and wall-wash lighting. Six delivered-lumen packages are published (nominal at 3000K, 80 CRI): 6,500 lm (1×30W), 8,500 lm (1×40W), 10,500 lm (2×40W), 12,500 lm (1×80W), 15,000 lm (1×93W) and 18,000 lm (2×53W), with custom output on request and efficacy up to 190 lm/W. White CCTs are 2700K, 3000K, 3500K, 4000K and 5000K (plus a 2700K–5000K tunable-white option and bread/meat/fish food-rendering variants) at CRI 80 or 90 (97 available), 3-step MacAdam. Optics follow a Dark Light concept with UGR<19 in Asymmetric (aisle), Wall-wash, 35° Flood, 50° Medium-wide and 80° Wide distributions. It runs on 120V, 277V or 347V (347V not available as a track version) with 0-10V, DALI or ON/OFF control. Housing colors are RAL 9016 white, RAL 9005 black and RAL 9006 silver plus custom, with black/white/metal gloss or matt shade finishes. Mounting options include Stucchi 2C/3C track, suspended, 10/15 ft aircraft-cable pendant, recessed and trimless recessed. Photometry is LM-79 tested by an NVLAP-accredited lab with LM-80 lumen maintenance, 50,000-hour reported life (TM-21-11), and a 5-year warranty on engine, driver and components; the fixture measures 6" × 22" × 3", weighs 4.8 lb (2.5 kg), and is assembled in Beloeil, Canada.
Pick from Suncatcher's published options to compose a copyable, submittal-ready specification. All choices come from the manufacturer datasheet — confirm the final build against the current revision before ordering.
Submittal summary
